jupyter-sphinx#

Sphinx extension that executes embedded code in a Jupyter kernel and embeds outputs in the document.

Documentation: https://jupyter-sphinx.readthedocs.io/
Source Code: https://github.com/jupyter/jupyter-sphinx

Basic Usage#

Use the jupyter-execute directive to embed executable code:

name = 'world'
print('hello ' + name + '!')

hello world!

All cells share the same kernel, so variables persist across cells:

a = 1
print('first cell: a = {}'.format(a))

first cell: a = 1

a += 1
print('second cell: a = {}'.format(a))

second cell: a = 2

Rich Output#

Plots#

import numpy as np
from matplotlib import pyplot
%matplotlib inline

x = np.linspace(1E-3, 2 * np.pi)
pyplot.plot(x, np.sin(x) / x)
pyplot.plot(x, np.cos(x))
pyplot.grid()

LaTeX#

from IPython.display import Latex
Latex(r'\int_{-\infty}^\infty e^{-x^2}dx = \sqrt{\pi}')

\[\int_{-\infty}^\infty e^{-x^2}dx = \sqrt{\pi}\]

Widgets#

Interactive widgets rendered via ipywidgets.

import ipywidgets as w
from IPython.display import display

Numeric#

Sliders#

display(
    w.IntSlider(value=5, min=0, max=10, description='IntSlider:'),
    w.IntRangeSlider(value=[3, 7], min=0, max=10, description='Range:'),
)

Progress Bars#

display(
    w.IntProgress(value=7, min=0, max=10, description='Default:'),
    w.IntProgress(value=5, min=0, max=10, description='Info:', bar_style='info'),
    w.IntProgress(value=8, min=0, max=10, description='Success:', bar_style='success'),
    w.IntProgress(value=3, min=0, max=10, description='Warning:', bar_style='warning'),
    w.IntProgress(value=6, min=0, max=10, description='Danger:', bar_style='danger'),
)

Boolean#

display(
    w.Checkbox(value=True, description='Checkbox'),
    w.ToggleButton(value=False, description='Toggle', icon='check'),
    w.Valid(value=True, description='Valid'),
    w.Valid(value=False, description='Invalid'),
)

Selection#

options = ['Option A', 'Option B', 'Option C']
display(
    w.Dropdown(options=options, value='Option A', description='Dropdown:'),
    w.RadioButtons(options=options, description='Radio:'),
    w.Select(options=options, description='Select:', rows=3),
    w.SelectMultiple(options=options, value=['Option A'], description='Multi:', rows=3),
    w.ToggleButtons(options=options, description='Toggles:'),
    w.SelectionSlider(options=options, description='Slider:'),
)

String#

display(
    w.Text(value='Hello', description='Text:'),
    w.Textarea(value='Multi-line\ntext input', description='Textarea:'),
    w.Password(value='secret', description='Password:'),
    w.Combobox(value='', placeholder='Type or select', options=['Apple', 'Banana'], description='Combobox:'),
)

Buttons#

display(
    w.HBox([
        w.Button(description='Default'),
        w.Button(description='Primary', button_style='primary'),
        w.Button(description='Success', button_style='success'),
        w.Button(description='Info', button_style='info'),
        w.Button(description='Warning', button_style='warning'),
        w.Button(description='Danger', button_style='danger'),
    ]),
    w.HBox([
        w.Button(description='', icon='home', tooltip='Home'),
        w.Button(description='', icon='search', tooltip='Search'),
        w.Button(description='', icon='cog', tooltip='Settings'),
        w.Button(description='', icon='download', tooltip='Download'),
    ]),
)

Date & Color#

display(
    w.DatePicker(description='Date:'),
    w.ColorPicker(value='#3b82f6', description='Color:'),
)

File Upload#

display(
    w.FileUpload(accept='.txt', description='Upload'),
)

Play / Animation#

play = w.Play(value=0, min=0, max=100, step=1, interval=100, description='Play:')
slider = w.IntSlider(value=0, min=0, max=100, description='Value:')
w.jslink((play, 'value'), (slider, 'value'))
display(w.HBox([play, slider]))

Containers#

Accordion#

display(w.Accordion(children=[
    w.Label('Content of section one'),
    w.Label('Content of section two'),
], titles=['Section 1', 'Section 2']))

Tabs#

display(w.Tab(children=[
    w.Label('Content of tab one'),
    w.Label('Content of tab two'),
], titles=['Tab 1', 'Tab 2']))

Tags Input#

display(w.TagsInput(value=['python', 'jupyter', 'widgets'], allowed_tags=['python', 'jupyter', 'widgets', 'sphinx']))

Linked Widgets#

slider = w.IntSlider(description='Value:', min=0, max=100, value=50)
progress = w.IntProgress(description='Progress:', min=0, max=100)
text = w.IntText(description='Number:')
w.jslink((slider, 'value'), (progress, 'value'))
w.jslink((slider, 'value'), (text, 'value'))
display(w.VBox([slider, progress, text]))

Directive Options#

Hide Code#

Use :hide-code: to show only output:

this code is invisible

Hide Output#

Use :hide-output: to show only code:

print('this output is invisible')

Code Below#

Use :code-below: to display code after output:

this code is below the output

print('this code is below the output')

Line Numbers#

Use :linenos: to add line numbers:

print('A')
print('B')
print('C')

A
B
C

Use :lineno-start: to start from a specific line:

print('A')
print('B')
print('C')

A
B
C

Emphasize Lines#

Use :emphasize-lines: to highlight specific lines:

d = {
    'a': 1,
    'b': 2,
    'c': 3,
    'd': 4,
    'e': 5,
}

Exception Handling#

Use :raises: to display tracebacks as output instead of failing the build:

1 / 0

---------------------------------------------------------------------------
ZeroDivisionError                         Traceback (most recent call last)
Cell In[26], line 1
----> 1 1 / 0

ZeroDivisionError: division by zero

Specify exception types to catch only specific errors:

a = {'hello': 'world!'}
a['jello']

---------------------------------------------------------------------------
KeyError                                  Traceback (most recent call last)
Cell In[27], line 2
      1 a = {'hello': 'world!'}
----> 2 a['jello']

KeyError: 'jello'

stderr Output#

Use :stderr: to display stderr output without build warnings:

import sys
print("hello, world!", file=sys.stderr)

hello, world!

Manual Cells#

Use jupyter-input and jupyter-output for non-executed code samples:

import time

def slow_print(str):
    time.sleep(4000)    # Simulate an expensive process
    print(str)

slow_print("hello, world!")

hello, world!

Rich Outputs#

HTML#

from IPython.display import HTML

HTML("""
<div style="padding: 1rem; border: 2px solid #3b82f6; border-radius: 8px;">
    <strong>Custom HTML</strong>
    <p>Rendered HTML output from IPython.display.</p>
</div>
""")

Custom HTML

Rendered HTML output from IPython.display.

Images#

from IPython.display import Image

Image(url="https://picsum.photos/400/400", width=400)

DataFrames#

import pandas as pd

data = {
    "Name": ["Alice", "Bob", "Charlie"],
    "Score": [95, 87, 92],
    "Grade": ["A", "B+", "A-"]
}
pd.DataFrame(data)

	Name	Score	Grade
0	Alice	95	A
1	Bob	87	B+
2	Charlie	92	A-
